IQ TESTER V1.5 IS HERE
SMARTER, FASTER, AND MORE POWERFUL THAN EVER
The ProPlex® IQ Tester—the go-to tool for Network, PoE, LTC, DMX and RDM diagnostics—just leveled up.
With Version 1.5 professionals in lighting, video, audio, rigging, SFX and broadcast now get sharper tools, smarter protocols, and smoother operation at their fingertips.
IQ TESTER LV
True, All-in-One, Handheld Ethernet DMX Tester
New Features:
Manual IGMP Join/Leave
Advanced IGMP configuration now editable and saveable to SD card for future sessions.
Automatic Multicast Group Join
Supported protocols, including MA-Net3, now connect seamlessly—no extra setup needed.
Simultaneous Art-Net Time-Code Stream Support
Receive and monitor multiple timecode feeds simultaneously for complex show workflows.
Selectable PoE Test Modes
Now specify Mode A, Mode B, or both—get exactly the diagnostic detail you need.
What Else Is New in v1.5?
Smarter Battery Management
Improved SoC accuracyCleaner Firmware Utility Interface
AppleDouble “dot underscore” files are now hiddenExpanded Protocol Detection
Now detects TCNet and Pioneer Pro DJ Link (8-bit subnet support in beta)Enhanced DMX Views
Orange indicators now show the last received data in paused transmissionsStreamlined DMX CMD Editing
New keypad logic reduces errors and adds button/rotary encoder support
Reliability Where It Counts — Key Updates Include:
• Resolved network config crash issues
• Improved handling of invalid IPs and file system errors
• Restored directed broadcast support outside local subnet
• Auto-recovers from invalid IP configs and avoids subnet conflicts
• Improved DHCP and static switching
• Enhanced Art-Net Time-Code UI
• Improved DMX scope timing and RDM sensor compatibility
• Corrected RGB/16-bit channel behavior in DMX transmitter
Core Capabilities:
• Ethernet diagnostics: See exactly what's on your network—and what’s causing problems
• Live protocol monitoring: sACN, Art-Net, MA-Net2/3, ETCNet, SMPTE and Art-Net Timecode, plus…
• DMX toolkit: Transmit, receive, scope, patch and troubleshoot instantly
• Portable and rugged: Designed for field use anywhere
• Touchscreen UI: Intuitive navigation for all experience levels
With the V1.5 enhancements, the ProPlex IQ Tester is now more powerful, capable, reliable, and intuitive—ready for the most demanding production environments.
Experience the smarter way to test, verify, and control
